This is the classic Acewell speedometer: an ACE-3100 digital speedo and rev counter with a clock, plus a clip-on surround holding 6 warning lamps.
It is fitted as original equipment on a range of Gas-Gas, Honda, Jawa and TGB motorcycles and ATVs.
warning lamp options
Model Number Positive switching Negative Switching
ACE-3700
ACE-3701
ACE-3702
ACE-3703
ACE-3802
ACE-3803
Features
features
Digial Speed Readout (SPD)
Maximum Speed Display (MAX SPD)
Average Speed Display (AVG)
Odometer (ODO)
Trip Meter
Clock
Resettable Riding Timer (RT)
Non-resettable Riding Timer (TT)
Warning Lamps
Warning Symbols Backlit
Digital Rev Counter
Programmable Shift Light
Bar Chart Rev Counter
Backlight
Waterproof Computer
Plastic Case
CNC Case
EMI/EMS Tested CE And E-Marked
Vibration (8G) And Mechanical Shock (100G) Tested.
Warning Lamps
warning lamps
Positive switching Negative Switching
Specifications
specifications Features Specification Model Number ACE-38xx Digial Speed Readout (SPD) 0 - 186MPH / 300Km/h Maximum Speed Display (MAX SPD) 0 - 186MPH / 300Km/h Average Speed Display (AVG) 0 - 186MPH / 300Km/h Max Speed Sensor Input Frequency 100Hz (reed sensor / hall sensor / cable drive speedo only) Odometer (ODO) 0-999,999 km / 0-624,999 miles Trip Meter 2 trips, 0-999 km / 0-625 miles Clock 12 / 24 hour clock, also displayed when ignition is off Resettable Riding Timer (RT) 0 - 99h 59min 59sec Non-resettable Riding Timer (TT) 0 - 9999h 59min Warning Lamps up to 8 depending on exact model Digital Rev Counter 0-20,000 RPM Bar Chart Rev Counter 0-11,000 RPM Operating Power 12v (DC, Negative earth) Backlight Blue backlight Connector Plugs 110 series Plastic Case Dimensions 130 x 78 x 28mm CNC Case Dimensions version AB or CP: 130 x 78 x 28mm Case black / silver & grey plastic with black surround or black / chrome CNC case Power On ignition key Compatible Wheel Size 1-3999mm
Included in the kit
included in the kit Head unit
Mounting Bracket: ACE-Y Stainless steel bracket
Mounting Kit: stainless steel nuts, washers, anti vibration washers
Speed Sensor: Reed sensor or hall sensor options
Mating multipin plugs and cables to solder / crimp into bike wiring (pigtails)
Operating Instructions
Wiring diagram
