ACE-260 : Digital display - Speedometer, warning lamps

£ 91.99 inc VAT | € 114.07 inc VAT | $ 117.29
ACE-260 Digital display - Speedometer, warning lamps
Product Images (Click to enlarge)
ACE-260 Digital display - Speedometer, warning lamps picture 1 ACE-260 Digital display - Speedometer, warning lamps picture 2

A small, rugged and waterproof multifunction computer with plenty of functions in a compact case.

This version is set up for cars and buggies, with the brake and rear fog warning lamps needed for the DVSA IVA test and the MOT on larger four-wheeled vehicles.

Modes: MPH, KM/H, ODO, TRIP, HRT, HRTT, RT, TT, CLOCK, MAX SPEED

Features

features
  • Digial Speed Readout (SPD)
  • Maximum Speed Display (MAX SPD)
  • Average Speed Display (AVG)
  • Odometer (ODO)
  • Trip Meter
  • Clock
  • Resettable Riding Timer (RT)
  • Non-resettable Riding Timer (TT)
  • Warning Lamps
  • Warning Symbols Backlit
  • Bar Chart Fuel Gauge
  • Backlight
  • Waterproof Computer
  • Plastic Case
  • EMI/EMS Tested CE And E-Marked
  • Vibration (8G) And Mechanical Shock (100G) Tested.

Warning Lamps

warning lamps
Positive switchingNegative SwitchingLCD symbols
Left indicator warning lampHigh beam warning lampSide lights warning lampGear position warning lampRight indicator warning lamp Brake warning lamp Fuel warning lamp

Specifications

specifications
FeaturesSpecification
Model NumberACE-260
Digial Speed Readout (SPD)0 - 248MPH / 400Km/h
Maximum Speed Display (MAX SPD)0 - 248MPH / 400Km/h
Average Speed Display (AVG)0 - 248MPH / 400Km/h
Max Speed Sensor Input Frequency100Hz (reed sensor / hall sensor / cable drive speedo only)
Odometer (ODO)0-999,999 km / 0-624,999 miles
Trip Meter2 trips, 0-999 km / 0-625 miles
Clock12 / 24 hour clock, also displayed when ignition is off
Resettable Riding Timer (RT)0 - 99h 59min 59sec
Non-resettable Riding Timer (TT)0 - 9999h 59min
Warning Lamps6
Operating Power12v (DC, Negative earth)
Bar Chart Fuel Gauge Input Resistanceoff or +/- 100 / 250 / 510 ohm
BacklightWhite backlight
Connector Plugs110 series
Plastic Case Dimensions96 x 53 x 24mm
Caseblack / silver plastic
Power Onignition key
Compatible Wheel Size1-3999mm

Included in the kit

included in the kit
  • Head unit
  • Mounting Bracket: ACE-Y Stainless steel bracket
  • Mounting Kit: stainless steel nuts, washers, anti vibration washers
  • Speed Sensor: Reed sensor or hall sensor options
  • Mating multipin plugs and cables to solder / crimp into bike wiring (pigtails)
  • Operating Instructions
  • Wiring diagram
Product Images
(Click to enlarge)
CategoryAcewell Speedometers
Sub-CategoryACE- 2xx
Quantity in Stock0

Buy This Product
Base Price
£ 91.99 inc VAT

Quantity
Case Colour
Speed Sensor

Related Products

ACE-6R2S ACE-6R2S £ 5.99 inc VAT Silver cover for ACE-2xx computers
